Introduction

The tBOX500-510-FL comes with the onboard 7th generation Intel® Core™ or Intel® Celeron® processor 3965U along with onboard two DDR4-1866/2133 SO-DIMM slots supporting up to 32GB system memory. It offers two I/O module slots and a wide selection of value-added modules (VAM) to meet different user requirements and customizations. The rugged tBOX500-510-FL is certified with E-Mark, ISO 7637-2, EN 50155, EN 50121, DNV 2.4, EN 45545-2 and IEC 60945. It supports a wide temperature range from -40°C to +70°C and anti-vibration of up to 3 Grms.

The fanless embedded box PC equipped with intelligent power management offers ACC on/off delay, shutdown delay and over/under voltage protection. It supports a wide voltage input range: 12/24 VDC for vehicle applications. 24 to 110 VDC for railway applications, and 24V DC for marine applications. For system integrators with extensive storage needs, the box computer offers two swappable 2.5” SATA HDDs and one mSATA. The new transportation embedded system is well suited for transportation-related applications such as security surveillance, onboard devices controller, truck fleet management, data transfer, and onboard passenger infotainment system.
