Introduction

The CEM310, a COM Express Type 10 Mini module, supports Intel® Atom® x5 and x7 processors (codename: Apollo Lake). In a board size of 84mm x 55mm. It has 8GB of DDR3L onboard memory and an optional 64GB eMMC memory. The Intel® Atom®-based COM Express Type 10 Mini module comes with a variety of I/O and expansion options including four PCIe x1 lanes. One Gigabit LAN port with Intel® i210IT Ethernet controller, two USB 3.0, eight USB 2.0, two SATA-600, four digital I/O channels. HD Codec audio, one DDI, one LVDS, one LPC, one SPI, two serial TX/RX and one I2C to meet customer requirements.

Aside from the rich I/O options, the CEM310 has a wide voltage input range of 4.75V to 20V to meet the varying voltage input requirements for automotive or transportation applications. In addition, it supports an extended operating temperature range from -20ºC to +70ºC or optional -40ºC to +85ºC to ensure stable and reliable operation in harsh environments. The CEM310 supports watchdog timer. Hardware monitoring functions, SMBus as well as smart battery (optional).
