GENE-TGU6
GENE-TGU6 - Image 2
GENE-TGU6 - Image 3
GENE-TGU6 - Image 4

GENE-TGU6

3.5” SubCompact Board with 11th Generation Intel® Core™ i7/i5/i3/Celeron® Processor SoC

  • DDR4 SODIMM Slot x 2, up to 64GB, support IBECC
  • HDMI 2.0 x 1, DP 1.4 x 2, Type-C DP x 1, LVDS/eDP x 1
  • 2.5GbE x 1, GbE x 1
  • USB 3.2 Gen 2 x 4, USB 2.0 x 2, USB Type-C x 1
  • M.2 2280 M-Key x 1, M.2 2230 E-Key x 1
  • Wide DC Input 9~36V (Optional: 12V Only)

Letölthető adatlap

Cikkszám: AAEON GENE-TGU6 Kategóriák: , , , , Címkék: , , , ,

Leírás

GENE-TGU6

The TGU6 from AAEON is built to bring greater performance, more flexibility and support for a broader range of applications than before. 11th Generation Intel® Core™ U processors (formerly Tiger Lake) deliver up to 20% better performance over previous generations of embedded processors. The embedded Intel® Iris® Xe graphics powers brilliant high definition video, with the GENE-TGU6 offering five video outputs supporting up to four simultaneous displays up to 4K.

With built-in compatibility with the Intel® distribution of OpenVINO™ toolkit, along with Intel Deep Learning Boost™. The TGU6 is capable of AI compute performance 30~40% greater than previous generations. GENE-TGU6 is built tough to handle harsh industrial and embedded environments with wide operating temperatures (-40°C to 85°C) and wide voltage input (+9V ~ +36V). Additionally, the GENE-TGU comes with a range of important features including TPM2.0, 2.5Gbps LAN and USB Type-C and DP1.4 ports, as well as multiple M.2 expansion slots.

További információkért és ajánlatért az AAEON GENE-TGU6 terékünkről keressen minket bizalommal! Ipari jelőléstechnikai termékeinkért tekintse meg testvéroldalunkat! Tartós, megbítható és extrém körülmények közt is stabil teljesítményt nyújtó ipari eszközök széles választékával várjuk
