SRT-IMX8P
SRT-IMX8P 3
SRT-IMX8P - Image 3

SRT-IMX8P

Standard IoT Gateway with ARM i.MX8M Plus Quad-Core Cortex-A53 1.6GHz Processor

  • NXP i.MX8M Plus Quad Cortex-A53 1.6 GHz RISC Processor
  • Onboard LPDDR4 2GB / eMMC 16GB (Optional 4GB RAM/ eMMC 32GB)
  • HDMI 2.0a
  • GbE x 2
  • USB 3.0 x 2, Full size mPCIe x 2, CAN-FD x 2 CH, Micro SD Card Slot x 1, RTC, TPM 2.0
  • Wide DC Input 9~36V
  • Wide Temperature -20 °C ~ 70 °C
  • UL61010 certificated; PLC and heavy industry IEC61000-6-2, IEC61000-6-4, IEC61131-2 qualified
  • Pre-Install Linux Debian 11; Support Android 13, Win 10 IoT, Yocto
  • Supports Modbus/ MQTT Library/ OPCUA/ Security boot/ GUI/ Machine learning eIQ (by request)
Cikkszám: AAEON SRT-IMX8P Kategóriák: , , Címkék: , , , Márka:

Leírás

SRT-IMX8P

Standard IoT Gateway with ARM i.MX8M Plus Quad-Core Cortex-A53 1.6GHz Processor

SRT-IMX8P SYSTEM

processor ARM NXP i.MX8M Plus Quad-Core Cortex-A53 1.6GHz Processor (NPU Optional)
Memory Onboard LPDDR4 2GB (Optional 4GB)
Storage eMMC 5.1 16GB (Optional 32GB)
Real Time Clock RTC x 1, with 3V CR2032H Lithium battery
Security TPM 2.0
Indicator Programmable LED control x 7
Cellular Mini PCIe Connector x 1 (USB signal)
Wireless Lan Mini PCIe Connector x 1 (USB signal)
Operating System Debian 11(Default, GUI is optional)
Android 13
Win 10 IoT
Yocto
Support Protocol —

SRT-IMX8P I/O

Serial Port RS-232/422/485 switchable x 2, Phoenix Connector
Ethernet Gigabit Ethernet x 2, RJ-45
USB USB 3.0 Type-A x 2
ADC —
DI/DO —
Can Bus CAN-FD x 2 CH, Phoenix Connector
Display HDMI 2.0a x 1
Power Connector 2 Pin 3.81mm Pitch Phoenix Connector
Debug Port Micro USB x 1
Expansion Slot SIM card slot x 1
Micro SD slot x 1
Other Interface Board to board connector to ODM board (PCIe Gen3 x 1, USB 3.0 x 1, I2C x 2,
GPIO x 4)

SRT-IMX8P POWER SUPPLY

Power Requirement DC 9-36V
Power Consumption 9.36W (Full Loading)
MTBF (hours) 479,374

ENVIRONMENTAL AND MECHANICAL

Dimension 3.66” x 5.43” (93 x 138mm)
Weight 0.7lb (350 g)
Mounting —
Operating Temperature -4 °F ~ 158 °F (-20 °C ~ 70 °C)
Storage Temperature -40 °F ~ 176 °F (-40 °C ~ 80 °C)
Operating Humidity 10% ~ 95% relative humidity, non-condensing
Certification CE/FCC Class A
UL61010/IEC61000-6-2/IEC61000-6-4/IEC61131-2

További információkért és ajánlatért az AAEON SRT-IMX8P terékünkről keressen minket bizalommal! Ipari jelőléstechnikai termékeinkért tekintse meg testvéroldalunkat! Tartós, megbítható és extrém körülmények közt is stabil teljesítményt nyújtó ipari eszközök széles választékával várjuk
