UP Squared offers developers an up to date platform based on the popular UP Squared board, offering greater expandability and I/O features as well as support for 5G and AI accelerators. The UP Squared Pro is powered by the Intel® Celeron® N3350, Pentium® N4200 and Atom™ E3950 processors (formerly known as Apollo Lake) with up to 8GB of onboard memory to power automation or AI Edge Computing.

The board provides greater expandability thanks to three M.2 slots, including M.2 2230 E-Key, M.2 2280 M-Key, and M.2 3042/3052 B-Key. This lets developers and users to quickly add on functionality such as Wi-Fi and AI accelerators such as the Intel® Movidius® Myriad™ X. The Squared Pro also supports 5G cellular cards, allowing developers to take advantage of lower latency and higher speeds for wireless network deployment.UP Squared features a 40-pin HAT expansion as well, and offers expandable storage with SATA III connectors.

UP Squared Pro maintains and grows the familiar UP ecosystem, allowing developers to easily migrate projects from the UP Squared board to UP Squared. Board is also compatible with the Intel® Distribution of OpenVINO® Toolkit. Providing powerful software to help developers get their projects up and running quickly.
